Host old apps in containers with Debian 12

I have recently had to start some software based on a very old PHP version. Since having that directly on the operating system will open it to vulnerabilities, containerization seems to be a good choice.

To accomplish this task we will use a VPS from DigitalOcean, also known as a droplet. We will start with steps to minimally harden the security of the droplet, then use Docker as that is the most popular option for containerization.

Then we will integrate it with our hosting solution based on the popular Virtualmin. We will assume that Virtualmin is already setup on your other server. Some help for that you might find here:

https://draghici.net/2023/11/15/a-small-hosting-server-with-virtualmin-and-debian-12/

https://www.debian.org/intro/why_debian
https://www.digitalocean.com/ (with referral link)
https://www.docker.com/
https://www.virtualmin.com/

Improve the operating system

We made these steps many times on this site until now. With only slight variations, the steps to follow will be the same. And every good thing starts with an update: 🙂

sudo apt update && sudo apt upgrade -y

https://draghici.net/2023/11/15/a-small-hosting-server-with-virtualmin-and-debian-12/

Looks and performance

Everybody wants a nice way to interact with their command line, which includes pretty fonts and fast response from your server.

zsh

We will start by making the prompt prettier:

sudo apt-get install zsh git
sudo wget -O /usr/local/bin/install_antigen https://raw.githubusercontent.com/cristidraghici/debian-server-bash-scripts/master/install_antigen.sh && sudo chmod +x /usr/local/bin/install_antigen
install_antigen
Maybe remember to update /etc/passwd to use zsh as your default shell.

Swap

We will also create a swap file, especially if we are not using SSDs:

sudo fallocate -l 4G /swapfile || dd if=/dev/zero of=/swapfile bs=1024 count=$((4*1024*1024))
sudo chmod 600 /swapfile
sudo mkswap /swapfile
sudo swapon /swapfile
echo "/swapfile none swap sw 0 0" | sudo tee -a /etc/fstab

Locales

We also need to clarify the locales:

sudo apt install locales
sudo dpkg-reconfigure locales

Security

Hardening the security of your server is one of the main concerns and taking the following steps is the minimum thing to do.

sudoer

The first step is to add a sudo user:

adduser sudouser
usermod -aG sudo sudouser
passwd -l root
su - sudouser

Then we will generate our SSH key:

mkdir ~/.ssh
touch ~/.ssh/authorized_keys
sudo apt update && sudo apt install openssh-client
ssh-keygen
chmod 700 ~/.ssh
chmod 400 ~/.ssh/id_rsa
chmod 600 ~/.ssh/authorized_keys

The next step will be to setup the access via an ssh key:

cat ~/.ssh/id_rsa.pub # on your own system to get your public key
nano ~/.ssh/authorized_keys
paste the content of your key and save with Ctrl+X

Ports

Another thing is to change the ssh port to a different one than the default:

sudo sed -i 's/#Port 22/Port 2222/' /etc/ssh/sshd_config
sudo sed -i 's/PermitRootLogin yes/PermitRootLogin no/' /etc/ssh/sshd_config
sudo systemctl restart sshd

fail2ban

Fail2ban is an open-source security tool designed to protect servers from brute-force attacks and unauthorized access by monitoring system logs for suspicious activity, such as repeated failed login attempts.

sudo apt-get install fail2ban -y
sudo cp /etc/fail2ban/jail.conf /etc/fail2ban/jail.local
sudo systemctl start fail2ban
sudo systemctl enable fail2ban

Firewall

One last thing will be to add the ufw firewall, but first we have to make sure firewalld is removed:

sudo systemctl stop firewalld
sudo systemctl disable firewalld
sudo apt purge firewalld

Now we add ufw:

sudo apt-get install ufw -y
sudo ufw default deny incoming
sudo ufw default allow outgoing
sudo ufw allow OpenSSH # opens port 22
sudo ufw allow in "WWW Full"
sudo ufw allow 2222/tcp # use the port set for your ssh server
sudo ufw allow from 192.168.0.0/16 to any port 22
yes | sudo ufw enable

To remove a rule:

sudo ufw status verbose
sudo ufw status numbered
sudo ufw delete <number to delete>

Once you do changes, make sure to reload ufw:

sudo ufw reload

Setup containerization

When solving the problem of old web applications, we have multiple choices out of which two stand out.

The first that used to come to mind was to create a VPS with the exact configuration that the application needs. However, this might mean older and unmaintained versions of the operating system which has the dependencies your app has, which open up to big security concerns.

The second and recommended path is to use some containerization solution. You still have to pay attention at how you create your container, as there are many quick downfalls (e.g. using root at your user in your image).

There are multiple ways we can go to create and run the containers: docker, podman, containerd.

Docker installation

The most used choice for containerization is Docker, which is the go to solution when it comes to containerization, often going hand in hand with the docker-compose.

First of all, install the dependencies and add the repository to the OS:

sudo apt install -y ca-certificates curl gnupg
sudo install -m 0755 -d /etc/apt/keyrings
curl -fsSL https://download.docker.com/linux/debian/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg
sudo chmod a+r /etc/apt/keyrings/docker.gpg
echo \ "deb [arch="$(dpkg --print-architecture)" signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/debian \ "$(. /etc/os-release && echo "$VERSION_CODENAME")" stable" | \ sudo tee /etc/apt/sources.list.d/docker.list > /dev/null

Then we can actually install docker and docker-compose and add ourselves to the docker group, so that we won’t have to use sudo. Make sure you remember to logout and login again.

sudo apt update
sudo apt install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin
sudo systemctl enable --now docker
sudo usermod -aG docker $USER
sudo apt install -y docker-compose-plugin

We can remove docker with the following commands:

sudo apt purge docker-ce docker-ce-cli containerd.io docker-buildx-plugin
sudo rm -rf /var/lib/docker
sudo rm -rf /etc/apt/keyrings/docker.gpg
sudo rm /etc/apt/sources.list.d/docker.list

More info:

https://docs.docker.com/engine/install/debian/

Firewall rules

This might not be obvious, but by default docker overrides the rules enforced by ufw.

We can fix this situation by doing the following:

sudo nano /etc/docker/daemon.json
add the following json and save: { "iptables": false }
sudo systemctl restart docker

Be aware that this solution will isolate docker from the outside world. Among others, this means that you won’t be able so solve DNS inside a Dockerfile and thus access outside resources (e.g. run the apt update command successfully).

Host the application

As mentioned in the title, we are setting up an old php application on its own server. We could open the port directly, but that leads to some complications. On the one hand, we would need to handle certificates and on the other hand we would need to invest more time in ensuring data safety.

For our situation, we will use the mysql database on a virtual host in virtualmin, hosted on a different server. Obviously, we will use git and secrets and other tools which are now popular in an application’s lifecycle.

One important security consideration is that we will use the internal IP addresses provided by DigitalOcean. This way, even if we open some ports, the attacker will have to be inside our network to be able to exploit possible vulnerabilities.

Webmin, Virtualmin and Apache are dealt with on the Virtualmin. Docker is the main reference on the VPS we have created for the old application.

Webmin

Webmin goes hand in hand with Virtualmin. While the latter is specially designed to deal with hosting websites, the former deals with your base operating system.

What we need to do here is add some modules to Apache:

Navigate to Webmin > Servers > Apache Webserver
Go to Configure Apache Modules, and enable the following modules (if not already): proxy, proxy_http, proxy_connect, proxy_ajp (optional), then click Enable Selected Modules
Restart Apache: sudo systemctl restart apache2

More info:

https://webmin.com/

Virtualmin

Virtualmin will be responsible for acting like a proxy to the VPS containing the older PHP 7 version. Assuming our host is already created, we need to go to Virtualmin > Your host > Services > Configure Website > Edit Directives and apply the following rules:

ProxyPreserveHost On
ProxyPass / http://192.168.1.100:81/
ProxyPassReverse / http://192.168.1.100:81/Code language: Apache (apache)

Make sure it’s inside the <VirtualHost _:80> block (or \_:443 for HTTPS), or at root level if the VirtualHost tag is not visible.

Obviously, we assume the PHP 7 host has the internal ip of 192.168.1.100 and it runs on port 81.

Mysql

For storing the data, we have multiple choices we will use the virtualmin database via a port connection. An interesting alternative is using a SSH tunnel between the two servers.

Setup the account with access (remember to let `’` where they are in the mysql commands):

mysql -u root -p <root_password>
CREATE USER '<restricted_user>'@'<allowed_ip>' IDENTIFIED BY '<strong_password>';
GRANT ALL PRIVILEGES ON <database_name>.* TO '<restricted_user>'@'<allowed_ip>';
FLUSH PRIVILEGES;

Make sure you remember to bind mysql to 0.0.0.0 instead of the default 127.0.0.1. Also, be sure to check that the user you created actually has access to the database in the virtualmin virtual server.

Also, remember to check that the user has the proper permissions:

SELECT * FROM mysql.user WHERE User = '<restricted_user>' AND Host = '<allowed_ip>';
SELECT * FROM mysql.db WHERE User = '<restricted_user>' AND Host = '<allowed_ip>' AND Db = '<database_name>';
SHOW GRANTS FOR '<restricted_user>'@'<allowed_ip>';

More information:

ufw

In case you have ufw enabled on your server as a firewall, you need to change some rules for both servers.

On the old app server, we need to open the port of the app (e.g. 8080) to the internal ip of the other server:

sudo ufw allow from <virtualmin_server_ip> to any port 8080 proto tcp

On the Virtualmin server we need to allow access to the mysql port:

sudo ufw allow from <old_application_server_ip> to any port 3306 proto tcp

https://www.digitalocean.com/community/tutorials/how-to-set-up-a-firewall-with-ufw-on-debian

Final thoughts

Such an implementation will help with your needs, but the best solution is obviously updating your application to be able to use the latest versions of its dependencies. Or removing it from your apps, in case it’s not important enough.
